Product name:
Heat Resistant And Low MOQ Self Adhesive Silicone Tape For Bus Bar
Applications:
For cable and wire connections
For Bus bar insulation
bus bar bolted connections
Moisture seal for automobile protective,tunnel and aerospace
| Product name |
Length
(±0.05)M
|
Width
(±1.5)mm
|
Thickness
(±0.05)mm
|
Parameters |
| Heat Resistant Silicone Rubber Electrical Tape |
5 |
50 |
0.5 |
See below chart |
| Heat Resistant Silicone Rubber Electrical Tape |
5 |
50 |
0.8 |
See below chart |
Good electrical waterproof tunnel leakage repair tape silicone self fusing tap Technical Parameters:
| No. |
Items |
Test standard |
Unit |
Results |
| 1 |
Hardness |
GB/T 531.1-2008 |
Shores A |
50±10 |
| 2 |
Tensile strength |
GB/T 528-2009 |
Mpa |
≥4.5 |
| 3 |
Elongation at break |
GB/T 528-2009 |
% |
≥350 |
| 4 |
Dielectric coefficient |
GB/T1408.1-2006 |
KV/mm |
≥22 |
| 5 |
Volume resistivity |
GB/T1410-2006 |
Ω.cm |
≥1.3*1015 |
| 6 |
Self-adhesive |
ASTM D2148 |
N/cm |
>3.5 |
| 7 |
Water absorption |
|
% |
<0.9 |
| 8 |
density |
GB/T 20631.2 |
g/cm3 |
<1.5 |
| 9 |
Flame retardant |
grade |
UL-94 |
V0 |
| 10 |
Heat resistant temperature |
|
|
180 |
| 11 |
Withstand voltage |
|
|
15KV |
| 12 |
Color |
|
|
Red, yellow, green etc |
Features:
1: Excellent flame retardant properties
2: Excellent heat resistance characteristics
5: Flexible over wide temperature range
6: Good quality, can be used in 180℃ for long time use.
7: Excellent weather resistance properties
Application:
| No |
Items |
| 1 |
Can be used for high voltage cable end with very good resistance function to electricity arc and tracking, suitable for winding on all kinds of power cable insulation materials. |
| 2 |
Can be used in insulation protection of electrical cabinets |
| 3 |
Can be applied to thermal insulation class H |
| 4 |
Can be applied to high temperature resistant cable of flame retardant requirement |
FAQ
1. Who are we?
We are professional in cold shrink industry. Our products have been exported to America, Australia, Egypt, Taiwan, India, Indonesia, Egypt, Spain, Italy and Germany etc, Europe countries. Currently, we already cooperated many famous companies in electrical and telecommunication industry.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
Up and download series product.
4. Why should you buy from us not from other suppliers?
Years focus on telecom and power infrastructure material, with experienced engineer and workers, with turnkey solution for cold shrink line to solve all your problem in this industry with competitive price.
5. What services can we provide?
Accepted Delivery Terms: FOB, CIF, EXW standard international terms and welcome commercial terms discussion;
Accepted Payment Currency: USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T, L/C, Credit Card, PayPal, Western Union, Cash, Escrow;
Language: English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
Shipment: express, sea and air shipping.
